SPECIFICATIONS TSB Revision EXTERIOR 51-35 HEATING ELEMENT FUNCTION CHECK For vehicles with heated door mirrors, check that there is conti- SPECIFICATIONS FASTENER TIGHTENING SPECIFICATIONS M1511015300235 SERVICE SPECIFICATIONS M1511000300240 AC000443 ITEM SPECIFICATION Side step 58 ± 7 N⋅m (43 ± 5 in-lb) Windshield wiper and washer 24 ± 3 N⋅m (18 ± 2 ft-lb) Wiper link assembly bolt 4.9 ± 1.0 N⋅m (44 ± 8 in-lb) Wiper motor assembly bolt 8.9 ± 1.9 N⋅m (79 ± 17 in-lb) Inlet assembly bolt 4.9 ± 0.7 N⋅m (44 ± 6 in-lb) Washer tank assembly bolt 4.9 ± 0.7 N⋅m (44 ± 6 in-lb) Rear wiper and washer 8.0 ± 1.2 N⋅m (71 ± 10 in-lb) Wiper motor assembly bolt 4.9 ± 0.7 N⋅m (44 ± 6 in-lb) Washer tank assembly bolt 4.9 ± 0.7 N⋅m (44 ± 6 in-lb) Washer motor bolt 4.9 ± 0.7 N⋅m (44 ± 6 in-lb) ITEM STANDARD VALUE Windshield wiper blade position Driver's side 20 − 30 (0.8 − 1.2) Passenger's side 25 − 35 (1.0 − 1.4) Rear wiper blade position installation mm (in) 25 − 35 (1.0 − 1.4) |
