Mitsubishi Lancer Evolution IX. Manual - part 99





AC211593

Note
(1)         : Clip positions
(2)         : Claw positions

Section D – D

A

B

C

View A

View B

View C

Rear door trim

D

D

E

E

F

F

F

F

F

F

F

F

E

E

Power window switch
panel assembly

G

G

Cap

Section F – F

Clip

Door panel

Rear door trim

Section E – E

Rear door trim

Clip

Power window switch
panel assembly

Section G – G

Cap

Pull handle box

Claw

Power window switch
panel assembly

Claw

Rear door trim

AF

<Rear door trim>

DOOR TRIM

INTERIOR

52A-15

DOOR TRIM

INTERIOR

52A-16

REMOVAL SERVICE POINT
<<A>> DOOR INSIDE HANDLE COVER
REMOVAL

AC100003AB

Tapping screw cap

1. Insert a flat-tipped screwdriver into the rear end of

the tapping screw cap on the door inside handle
cover, and pry out the cap in the direction shown.
Then remove the tapping screw.

AC504658

A

A

Special tool
insertion
position

Door inside
handle cover

MB990784

Claw

Section A – A

Door inside
handle cover

AB

Door trim

2. Insert special tool ornament remover (MB990784)

into the clearance between the door inside handle
cover and the door inside handle, and disengage
the claws of the door inside handle.

3. Insert special tool ornament remover (MB990784)

into the rear end of the inside handle cover, and
pry out the cover in the direction shown. Then
remove the door inside handle cover.

HEADLINING

INTERIOR

52A-17

HEADLINING

REMOVAL AND INSTALLATION

M1521001400393

Pre-removal and Post-installation Operation
Front Pillar Trim, Centre Pillar Trim Upper, Rear pillar Trim
Removal and Installation (Refer to

P.52A-10

).

AC304633

1

2

3

4

4

5

5

6

AB

Removal steps

1.

Assist grip

2.

Room lamp assembly

3.

Front room lamp

<<

A

>>

4.

Sunvisor holder

5.

Sunvisor assembly

Front floor console assembly (Refer
to

P.52A-7

).

<<

B

>>

6.

Headlining

REMOVAL SERVICE POINTS
<<A>> SUNVISOR HOLDER REMOVAL

AC304786

Sunvisor holder

MB990784

MB990784

AB

Insert the special tool ornament remover
(MB990784) into the claws of the sunvisor holder to
remove the hinges.

<<B>> HEADLINING REMOVAL

Bend the headlining to removal from the front pas-
senger’s door.

Removal steps (Continued)

INSIDE REAR VIEW MIRROR

INTERIOR

52A-18

INSIDE REAR VIEW MIRROR

M1521002600260

REMOVAL SERVICE POINT

AC209066

Claw B

Claw A

Cover

1

2

3

AC

1. Disengage claw A and lower the cover in the

arrow 1 direction.

2. Push claw B in the arrow 2 direction to unlock,

and pull out the mirror in the arrow 3 direction.

FRONT SEAT ASSEMBLY

REMOVAL AND INSTALLATION

M1522001300429

AC310714 AB

45 ± 10 N·m

45 ± 10 N·m

30 ± 5 N·m

1

1

2

Removal steps

1. Front seat anchor cover

>>

A

<< 2. Front seat assembly
