Mitsubishi Lancer Evolution IX. Manual - part 66

AC500088

A-15

A-31

A-18

A-33

A-03

A-12

A-05X
A-06X
A-07X
A-09X
A-10X
A-11X

A-02

A-13

A-29

A-17

A-19

Front wiring
harness (LH)

AB

12

A-44

A-21

(2-B)

Headlamp (HI: RH)

A-25

(2-BR)

Dual pressure switch

A-27

(2-B)

Wheel speed sensor (Front: RH)

A-29

(8-B)

Front wiring harness (LH) and control
wiring harness combination

A-31

(8-B)

Headlamp assembly (LH)

A-33

(2-Y)

Front impact sensor (LH)

A-34

(2-B)

Condenser fan motor

A-35

(2-GR)

Condenser fan motor

A-36

(1-B)

A/C compressor

A-37

(2-Y)

Front impact sensor (RH)

A-39

(8-B)

Headlamp assembly (RH)

A-40

(1-B)

Power steering fluid pressure switch

A-44

(2-BR)

Outside thermo sensor

ENGINE COMPARTMENT

CONFIGURATION DIAGRAMS

80-5

ENGINE COMPARTMENT

CONFIGURATION DIAGRAMS

80-6

ENGINE COMPARTMENT <RH drive vehicles>

M1801000302224

AC500090

AB

1

A-34

A-35

A-37

A-40

A-36

A-21

A-39

A-01

A-43

Front wiring
harness (RH)

A-27

A-25

A-42

Connector
symbol

A

Connector colour
code
B : Black
BR : Brown
G : Green
GR : Grey
L : Blue
None : Milk white
O : Orange
R : Red
V : Violet
Y : Yellow

A-01

(2-GR)

Side turn signal lamp (RH)

A-02

(2-GR)

Side turn signal lamp (LH)

A-03

(2-B)

Wheel speed sensor (Front: LH)

A-05X (4)

Horn relay

A-06X (4)

Condenser fan relay (LO)

A-07X (4)

Condenser fan relay (HI)

A-09X (4)

Fan control relay

A-10X (11)

Front-ECU

A-11X (11)

Front-ECU

A-12

(2-B)

Front wiring harness (LH) and control
wiring harness combination

A-15

(2-B)

Headlamp (HI: LH)

A-17

(3-GR)

Fan controller

A-18

(1-B)

Horn (HI)

A-19

(1-B)

Horn (LO)

AC500091

AB

A-02

A-03

A-05X
A-06X
A-07X
A-09X
A-10X
A-11X

A-12

A-18

A-33

A-17

A-19

Front wiring
harness (LH)

A-15

A-31

12

A-44

A-21

(2-B)

Headlamp (HI: RH)

A-25

(2-BR)

Dual pressure switch

A-27

(2-B)

Wheel speed sensor (Front: RH)

A-31

(8-B)

Headlamp assembly (LH)

A-33

(2-Y)

Front impact sensor (LH)

A-34

(2-B)

Condenser fan motor

A-35

(2-GR)

Condenser fan motor

A-36

(1-B)

A/C compressor

A-37

(2-Y)

Front impact sensor (RH)

A-39

(8-B)

Headlamp assembly (RH)

A-40

(1-B)

Power steering fluid pressure switch

A-42

(2)

No connection

A-43

(2-GR)

Brake fluid level switch

A-44

(2-BR)

Outside thermo sensor

ENGINE COMPARTMENT

CONFIGURATION DIAGRAMS

80-7

ENGINE AND TRANSMISSION

CONFIGURATION DIAGRAMS

80-8

ENGINE AND TRANSMISSION

ENGINE AND TRANSMISSION <LH drive vehicles>

M1801000401693

AC500093

AB

B-28

B-25

B-01

B-24

Connector
symbol

-01
thru
-30

B

Connector colour
code
B : Black
BR : Brown
G : Green
GR : Grey
L : Blue
None : Milk white
O : Orange
R : Red
V : Violet
Y : Yellow

B-20

B-22

B-29

B-02

B-23

B-01

(5-GR)

Windshield wiper motor

B-02

(2-B)

Purge control solenoid valve

B-03

(4-B)

Throttle position sensor

B-04

(3-B)

Vehicle speed sensor

B-05

(2-GR)

Brake fluid level switch

B-06X (1)

Engine speed detection connector

B-12X (4)

Engine control relay

B-13X (4)

A/C compressor relay

B-14

(10-B)

Control wiring harness and battery
wiring harness combination

B-17

(2-B)

Injector (4)
