Mitsubishi Lancer Evolution IX. Manual - part 28
ROOM LAMP, LUGGAGE COMPARTMENT LAMP, IGNITION KEY CYLINDER ILLUMINATION LAMP AND DOOR AJAR WARNING LAMP
CIRCUIT DIAGRAMS
90-91
IGNITION
SWITCH (IG1)
BATTERY
RELAY
BOX
KEEP RELAY
LOAD
DETERMINATION
CIRCUIT
FRONT
ROOM
LAMP
LUGGAGE
COMPARTMENT
LAMP
LUGGAGE
COMPARTMENT
LAMP SWITCH
POWER
SOURCE
·HEADLAMP
·HEADLAMP LEVELLING SYSTEM
·REAR FOG LAMP
·TAIL LAMP, POSITION LAMP,
LICENCE PLATE LAMP AND
LIGHTING MONITOR BUZZER
·TURN-SIGNAL LAMP AND
HAZARD WARNING LAMP
·WINDSHIELD WIPER AND
WASHER
·HEADLAMP
·REAR FOG LAMP
·TAIL LAMP,
POSITION LAMP,
LICENCE PLATE
LAMP AND LIGHTING
MONITOR BUZZER
·TURN-SIGNAL LAMP
AND HAZARD
WARNING LAMP
·WINDSHIELD
WIPER AND
WASHER
Wire colour code
B : Black LG : Light green G : Green L : Blue W : White Y : Yellow SB : Sky blue
BR : Brown O : Orange GR : Grey R : Red P : Pink V : Violet PU : Purple
