Mazda Training manual - part 178
T019/03
4 of 8
Mazda3 Special Tool(s):
The SST list of the sections, which are not mentioned in the following charts, doesn’t change from the SST
list, which was introduced in the service information (T008/03) of Mazda3 with gasoline engine.
1: Mazda SST number
2: Ford SST number
Engine (MZ-CD 1.6 (Y6))
49 E017 5A0
Engine
support
1: 49 UN30 3050
2: 303-050
Engine
lifting
bracket
49 0107 680A
Engine stand
49 L010 1A0
Engine
hanger
set
1: 49 JE02 020
2: 303-734
Locking tool,
crankshaft
49 B012 004
Valve seal
pusher
49 JE02 0A2
Universal
valve tool
49 0636 100B
Valve
spring
lifter
arm
49 B012 0A2
Pivot
1: 49 JE02 010
2: 303-172-02A
Adapter
1: 49 JE02 011
2: 303-172-05
Adapter
1: 49 JE02 009
2: 303-172-01
Adapter
1: 49 JE02 023
2: 303-738
Installer,
crankshaft
rear oil seal
1: 49 JE02 019
2: 303-733
Installer,
crankshaft
oil seal
49 B010 001
Oil seal
installer
1: 49 JE02 007
2: 303-034
Guide studs,
cylinder head
1: 49 JE02 012
2: 303-245
Alignment
pins,
cylinder head
1: 49 JE02 018
2: 303-732
Alignment peg,
crankshaft
1: 49 JE02 021
2: 303-735
Alignment peg,
camshaft
49 S120 215B
Pulley puller
1:49 JE02 050
2:310-110
Hand
pressure
pump set
