1
Verify if the reflector is set in the correct
position. (See BLIND SPOT
MONITORING (BSM) RADAR TEST.)
Is the reflector set in the correct position?
No
Set the reflector in the correct position and
perform the BSM radar test.
(See BLIND SPOT MONITORING
(BSM) RADAR TEST.)
2
RE-PERFORM BSM RADAR TEST
Perform the BSM radar test.
Repeat the BSM radar test up to four times
until "TEST PASSED" is displayed.
(See BLIND SPOT MONITORING
(BSM) RADAR TEST.)
Is "TEST PASSED" displayed?
Yes BSM radar test completed.
No
Go to the next step.
3
VERIFY EFFECT OF REAR BUMPER
Remove the rear bumper. (See REAR
BUMPER
REMOVAL/INSTALLATION .)
Perform the BSM radar test.
Repeat the BSM radar test up to four times
until "TEST PASSED" is displayed.
(See BLIND SPOT MONITORING
(BSM) RADAR TEST.)
Is "TEST PASSED" displayed?
Yes
Replace the rear bumper. (See REAR
BUMPER
REMOVAL/INSTALLATION .)
No
Go to the next step.
4
INSPECT BSM CONTROL MODULE FOR
INCORRECT INSTALLATION AND
DISTORTION AT VEHICLE
INSTALLATION SURFACE
Inspect the BSM control module for
incorrect installation and distortion at the
vehicle installation surface.
Is the BSM control module installed
correctly without distortion?
Yes Go to the next step.
No
Repair or replace the malfunctioning part,
then go to the next step.
5
PERFORM BSM RADAR TEST
Perform the BSM radar test.
Repeat the BSM radar test up to four times
until "TEST PASSED" is displayed.
(See BLIND SPOT MONITORING
Yes BSM radar test completed.
No
Replace the BSM control module. (See
BLIND SPOT MONITORING (BSM)
CONTROL MODULE
