76 CHASSIS AND BODY 16 REPAIR 7. To remove barrel from plastic retaining sleeve, depess spring loaded button and withdraw Refit NOTE: If a new barrel is being fitted, check 8. Push plastic retaining sleeve over barrel until spring loaded peg locks it into position. 9. Fit barrel and plastic sleeve assembly to locking sleeve and insert into exterior handle reversing 10. Assemble lock lever components as illustrated and from inside of door panel, fit them to barrel 11. Connect operating rod to lock lever and secure with spring clip, reversing instruction 4. 12. Fit mounting panel See Mounting panel - front door . DOOR STRIKER - ADJUST Service repair no - 76.37.23 - front door Adjust 1. Loosen 2 Torq bolts securing striker to body. horizontally, lightly tighten bolts. 3. Close door, check for correct latching with door lock and for centering on striker. 4. Add or remove packing shims as necessary behind striker and fully tighten bolts. 5. Carry out further adjustment as necessary. If full adjustment is not achieved carry out the 6. Remove striker and nut plate. direction required. 8. Refit striker and adjust as necessary. |
