C0633

CONNECTOR

DEFENDER 1999 MY

Module - Ignition amplifier -
V8

Female
BLACK

Front of engine - centre

Cav

Col

CCT

1

WB

ALL

3

W

ALL

CONNECTOR

C0658

DEFENDER 1999 MY

Engine control module
(ECM) - Td5

Female
BLACK

Beneath RH seat

P5594

C0158

C0658

Cav

Col

CCT

1

B

21

2

B

21

3

NO

21

4

BP

21

5

UP

21

6

RS

21

7

GU

21

9

YS

21

12

WG

21

13

YK

21

14

WP

21

16

GP

21

18

K

21

19

YK

12

Cav

Col

CCT

21

UR

21

22

NO

21

23

PB

21

24

B

21

25

B

21

26

BY

21

27

NO

21

29

BS

21

30

BY

21

32

SP

12

33

WG

21

34

LGS

21

35

BW

21

36

WS

21

C0666

CONNECTOR

DEFENDER 1999 MY

Sounder - Alarm - Battery
backed up

Female
BROWN

Behind LH headlamp

P5550

C0666

C0520

Cav

Col

CCT

1

B

27

2

B

27

3

B

27

4

B

27

CONNECTOR

C0667

DEFENDER 1999 MY

Switch - Clutch pedal - Td5

Female
BLACK

Adjacent pedal box

P5564

C0075

C0029

C1264

C0667

C1265

Cav

Col

CCT

1

BW

21

2

B

21
