C0574

CONNECTOR

DEFENDER 1999 MY

Fuse box - Engine
compartment

Female
NATURAL

Beneath RH seat

P5595

C0570

C0571

C0572

C0574

C0573

Cav

Col

CCT

1

PN

ALL

2

PN

ALL

3

NLG

21

CONNECTOR

C0580

DEFENDER 1999 MY

Fuse box - Passenger
compartment

Female
BLACK

Beneath centre console

P5771

C0580

C0581

Cav

Col

CCT

1

W

ALL

2

WG

15

4

WG

ALL

6

WG

ALL

8

GO

12

9

W

ALL

10

WG

ALL

Cav

Col

CCT

12

GY

ALL

14

WG

ALL

15

NW

ALL

16

P

27

17

NK

1

18

NP

1

20

NS

1

C0581

CONNECTOR

DEFENDER 1999 MY

Fuse box - Passenger
compartment

Female
BLACK

Beneath centre console

P5771

C0580

C0581

Cav

Col

CCT

1

R

ALL

2

RB

ALL

4

RO

ALL

5

WO

ALL

6

PG

ALL

8

WO

ALL

9

UR

ALL

10

UB

ALL

Cav

Col

CCT

12

UK

ALL

13

UW

ALL

14

UO

ALL

16

US

ALL

17

U

ALL

18

UP

ALL

19

PB

15

20

OR

15

CONNECTOR

C0615

DEFENDER 1999 MY

Switch - Boot / taildoor

Female
NATURAL

RH ’A’ post

P5649

C0615

Cav

Col

CCT

1

PU

ALL
