Jaguar XJ (2008 year). Manual - part 24

97

Clock

R

Clock

CLOCK ADJUSTMENT

The analogue clock is adjusted by
pressing the + and – buttons below the
dial. Pressing and holding either button
will increase the rate of hand movement
forwards or backwards as required.

E86362

Steering Column

98

L

Steering Column

STEERING COLUMN
ADJUSTMENT

!

WARNING:

Never adjust the steering wheel
position whilst the vehicle is in motion.
Doing so will reduce control of the
vehicle, and may cause unpredictable
steering movements.

The steering column can be adjusted for
tilt and reach by operating the control
switch on the left side of the steering
column.

Turn the switch to the COLUMN or AUTO
position.

Move the switch forwards or backwards
to adjust reach.

Move the switch up or down to tilt.

Three column positions may be stored
and recalled by the Driver Position
Memory system. See page 108.

ENTRY/EXIT MODE

Entry/exit mode provides automatic
movement of the steering column and
driver’s seat to allow easier entry to or exit
from the vehicle.

Entry/exit mode is selected by setting the
steering column adjustment switch to the
AUTO position.

Exit– If the ignition key is in position 0 and
the driver’s door is opened or if the
ignition key is removed, the steering
column will move to the uppermost tilt
position. The seat will move rearwards
unless it is already 40 mm (1.5 inches) or
less from its fully rearward position when
it will not move any further back.

Entry– When the key is next inserted in
the ignition switch and the door is closed,
the steering column and seat will return to
their previous positions. If, however, the
memorised driver position has been
changed (using the door memory switch
or another integrated key), the steering
wheel and seat will move to the new
position.

Caution: Do not use steering wheel
mounted security devices since
movement of the steering wheel in
entry/exit mode could result in vehicle
damage (e.g. the windshield) or
possible injury to the occupant.

E86302

99

Steering Column

R

Note:

•

If the adjustment switch is moved
away from AUTO whilst the steering
column is tilted away, the steering
column will move back to its
memorised position when the key is
next inserted in the ignition and
entry/exit mode is then cancelled.

•

If the adjustment switch is moved
during entry/exit operation, steering
column movement will stop.

Pedal Controls

100

L

Pedal Controls

PEDAL ADJUSTMENT

!

WARNING:

Do not adjust the pedals whilst driving.

This facility enables the pedals to be
moved towards or away from the driver’s
seat, providing extra adjustment for the
driving position. All pedals move together
(no individual pedal adjustment) and are
electrically controlled from the combined
steering column/pedal adjust switch on
the left side of the steering column
housing. The adjustment can be made
with or without the ignition key inserted.

To adjust the position of the pedals, turn
the switch to PEDALS, then push it
forwards or rearwards to cause a
corresponding movement of the pedal
assembly.

Three pedal positions may be stored and
recalled by the Driver Position Memory
system. See Driving Position Memory
on page 108. It will not be possible to
adjust the pedals if cruise control has
been set.

E86306
