Vehicle management and maintenance in winter
Use of anti-freeze fluid
The freezing temperature of the cooling water for engine will vary with the con鄄
tent of the anti-freezing fluid in it.
1. The correct mixing ratio of the anti-freezing fluid can be set according to the
curve shown in the figure on the left.
It is users' responsibility to keep right content of anti-freezing fluid correspond鄄
ing to the ambient temperature where the vehicle is used.
86
OWNER爷S MANUAL
JAC High end Light Trucks
Durable cooling water(glycol-based)
mix ratio(%)
2. It is better to wash the inside of the cooling system before glycol based
cooling water is used.
3. Any damaged rubber hose should be replaced, because the engine cooling
water will leak out even if the cracks are very small in the hose.
Engine oil
With the ambient temperature going down, the engine oil viscosity will go up.
Use the engine oil with viscosity suitable to the ambient temperature.
87
