1A–72 HEATING, VENTILATION AND AIR CONDITIONING (HVAC) Magnetic Clutch Assembly (DKV-14G Type) Parts Location View 871R200001 Legend (1) Drive Plate bolt (4) Pulley Assembly Removal 1. Using drive plate holder J-7624 (1) to prevent the drive plate from rotating, then remove the drive plate 871R200013 2. Remove drive plate by using drive plate puller J-33944-A (2) and forcing screw J-33944-4 (1). 871R200014 3. Remove shim (s). |
