6E–550 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS Accelerator Pedal Replacement Removal Procedure 1. Disconnect the negative battery cable. accelerator position sensor. 101RY00006 Legend (1) Accelerator Position Sensor 3. Remove the two screws from the accelerator pedal assembly. 101RY00007 4. Remove the accelerator pedal assembly from the bulkhead. Installation Procedure 1. Install the accelerator pedal assembly on the bulkhead. 2. Install the two screws to the accelerator pedal assembly. Tighten D Tighten the screws to 22 N·m (16 lb ft.). 101RY00007 3. Connect the electrical harness to the accelerator position sensor. 101RY00006 Legend (1) Accelerator Position Sensor 4. Install the negative battery cable. |
