6E–542 6VE1 3.5L ENGINE DRIVEABILITY AND EMISSIONS Intake Air Temperature (IAT) Sensor Removal Procedure 1. Disconnect the negative battery cable. the throttle body. 4. Disconnect the electrical connector from the IAT sensor. TS23741 5. Remove the IAT sensor from the intake air duct by using a rocking motion while pulling the sensor. Installation Procedure 1. Install the IAT sensor into the grommet in the intake air duct. 2. Correct the IAT electrical connector. TS23741 3. Install the engine cover. ION Sensing Module Removal Procedure 1. Disconnect the negative battery cable. the common chamber. 060RY00087 Installation Procedure 1. Install the ION sensing module on the common chamber with the bolts. Tighten D Tighten the ION sensing module to 4 N·m (35 lb |
