6A–55 ENGINE MECHANICAL (6VE1 3.5L) 1. Measure the valve stem diameter with a micrometer. If the valve stem diameter is less than the specified Diameter of Valve Stem (0.2353 in–0.2346 in) Limit : 5.90 mm (0.2323 in) (0.2343 in–0.2350 in) Limit : 5.90 mm (0.2323 in) 014RS007 2. Measure the inside diameter of the valve guide with a micrometer. Subtract the measured outer diameter of Inside Diameter of the Vale Guide (0.0009 in–0.0002 in) Limit : 0.20 mm (0.00787 in) (0.0012 in–0.0025 in) Limit : 0.20 mm (0.00787 in) Valve Guide Replacement 1. Using Valve guide replacer: J–42899, drive out the valve guide from the combustion chamber side. 014RS008 2. Apply engine oil to the outside of the valve guide. Using valve guide replacer J–42899, drive in a new Valve guide upper end height: 13.0 mm (0.5118 (Measured from the cylinder head upper face) 014RW046 3. Check the clearance. If the clearance is less than the specified value, ream the inside diameter of valve |
