6A–60 ENGINE MECHANICAL (6VD1 3.2L) 2. Remove twenty fixing bolts from inlet and exhaust camshaft bearing cap on one side bank, then 014RW027 3. Remove camshaft assembly (3), (4). gear retainer (8), then camshaft drive gear assembly. Inspection and Repair 1. Use a micrometer to measure the cam lobe height and uneven wear. Replace the camshaft if either the Lobe height : 44.709 mm (1.7602 in) 014RW043 2. Use a micrometer to measure the diameter and the uneven wear of the camshaft journals. Journal Diameter (1.0225 in–1.0233 in) Limit : 25.8 mm (1.0157 in) 014RS023 3. Place the camshaft on V–blocks. Slowly rotate the camshaft and measure the runout Run out 014RW044 |
