General Repair Instruction

1. If a floor jack is used, the following precautions are

recommended.
Park vehicle on level ground, “block" front or rear
wheels, set jack against the recommended lifting
points (see “Lifting  Instructions" in this section),
raise vehicle and support with chassis  stands and
then perform the service operations.

2. Before performing service operations, disconnect

ground cable from the  battery to reduce the chance
of cable damage and burning due to short circuiting.

3. Use a cover on body, seats and floor to protect them

against damage and contamination.

4. Brake fluid and anti–freeze solution must be

handled with reasonable care, as they can cause
paint damage.

5. The use of proper tools and recommended essential

and available tools,  where specified, is important
for efficient and reliable performance of service
repairs.

6. Use genuine Isuzu parts.

7. Used cotter pins, plastic clips, gaskets, O–rings, oil

seals, lock washers  and self–locking nuts should be
discarded and new ones should be installed,  as
normal function of the parts cannot be maintained if
these parts are reused.

8. To facilitate proper and smooth reassembly

operation, keep disassembled  parts neatly in
groups. Keeping fixing bolts and nuts separate is
very important,  as they vary in hardness and design
depending on position of installation.

9. Clean the parts before inspection or reassembly.

Also clean oil ports,  etc. using compressed air, and
make certain they are free from restrictions.

10. Lubricate rotating and sliding faces of the parts with

oil or grease before installation.

11. When necessary, use a sealer on gaskets to

prevent leakage.

12. Carefully observe all specifications for bolt and nut

torques.

13. When removing or replacing parts that require

refrigerant to be discharged  from the air
conditioning system, be sure to use the Vehicle
Refrigerant Recovery  and Recycling Equipment
(VRRRE) to recover and recycle Refrigerant–134a.

14. When a service operation is completed, make a final

check to be sure  the service has been done
properly and the problem has been corrected.

15. SUPPLEMENTAL RESTRAINT SYSTEM

The vehicle is equipped with a Supplemental
Restraint System (SRS) – Air Bags. This system is
not to be serviced without consulting the appropriate
service information.  Consult Section 9J “SRS
System" if work is to be done on the front of the
vehicle such as bumper, sheet metal, seats, wiring,
steering wheel or column.  Also review SRS system
information if any arc welding is to be done on the
vehicle. The SRS system equipped vehicle can be
identified by:

1. “AIR BAG" warning light on the instrument

cluster.

2. A Code “K" or “M" for fifth digit of Vehicle

Identification Number.

SECTION

0A–2

GENERAL INFORMATION

Illustration Arrows

Arrows are designed for specific purposes to aid your understanding of technical illustrations.

Arrow Type

A pplication

Front of vehicle

Up Side

Task Related

View Detail

View Angle

Dimension (1:2)

Sectioning (1:3)

• Ambient/Clean air flow

• Cool air flow

• Gas other than

ambient air

• Hot air flow

• Ambient air mixed with

another gas

• Can indicate

temperature change

Motion or direction

Lubrication point oil or
fluid

Arrow Type

Application
