4A2–14 DIFFERNTIAL (REAR) Inspecting the Axle Before 1. Remove the axle cover from the rear axle and drain the axle lubricant into a suitable container. 2. Check ring gear backlash. Refer to Backlash Adjustment in this section. This information can be 3. Check case for metal chips and shavings. Determine where these chips and shavings come from, such as D If possible, determine the cause of the axle problem Disassembly 1. Remove axle shafts. D Refer to axle shaft replacement in this section. 2. Remove ABS sensor. D Mark the caps and the housing as left and right. CAUTION: Bearing caps are machined with the 420RW003 4. Remove Differential case. D Pry the case from the axle housing at the differential 420RW010 5. Remove side bearing outer races and shims. D Mark the races and shims as left and right, and 6. Remove differential side bearings using remover J–42379 and plug J–39830. D Select insert ; 303174 and collet halves ; 44801 in 415RW003 7. Remove ring gear bolts. D Ring gear bolts use right handed threads. CAUTION: DO not pry the ring gear from the case. |
