4D2–39 TRANSFER CASE (TOD) Clutch Pack and Clutch Cam Disassembled View 266RW006 Legend (1) Clutch Pack Assembly (5) Wave Spring Reassembly 1. Mount the clutch pack assembly to which the multi plate disk clutch is already installed to the output NOTE: Mount the clutch pack assembly while adjusting 2. Install the insulator washer. |
