Isuzu KB P190. Manual - part 783

Engine Mechanical – V6

Page 6A1–355

Tool Number

Illustration

Description

EN-46117

Valve Stem Key Remover / Installer

Used in conjunction with J-8062 or EN-46110 to remove and
reinstall the valve stem keys.

EN-46119

Off-vehicle Valve Spring Compressor Adaptor

Used in conjunction with J-8062 to remove valve springs with
the engine disassembled.

EN-46120 and

J-42096

Valve Guide Reamer

Used to oversize valve guides prior to the installation of new
oversized valves.

EN-46121

Connecting Rod Guide Pin Set

Used to guide connecting rods onto the crankshaft journals
and prevent damage to the cylinder bores, journal faces and
piston cooling jets during engine assembly procedures.

EN-46122

Oil Control Valve Check Ball Remover / Installer

EN-7115

Torque Angle Wrench

Used to accurately tighten fasteners when an angle torque is
required.

Engine Mechanical – V6

Page 6A1–356

Tool Number

Illustration

Description

J-29184

Crankshaft Front Oil Seal Installer

J-36648-A

Oil Pressure Gauge Adaptor

j-41816

three legged puller

J-41818

Main Bearing Cap Removal Tool

Used in conjunction with J-6125-1B to remove the main
bearing caps from the cylinder block during engine
disassembly procedures.

J-41998-B

Crankshaft Balancer Installer

J-42385-2000

Thread Insert Kit

Used to repair damaged threads during engine overhaul.

J-42385-700

High Feature Thread Repair Kit

Used to repair damaged threads during engine overhaul.

Engine Mechanical – V6

Page 6A1–357

Tool Number

Illustration

Description

J-45027

Tensioner Tool

Used to reset the timing chain tensioner plunger.

J-6125-1B

Slide Hammer

Used in conjunction with J-41818 to remove the main bearing
caps from the cylinder block during engine disassembly.

J-8062

Valve Spring Compressor

Used in conjunction with EN-46119 to remove valve springs
with the engine disassembled.

J-8087

Cylinder Bore Gauge

Commercial equivalent also available

EN-48313

Timing Chain Retention Tool

Engine Mechanical – V6

Page 6A1–358

MY2005 VZ

6A1

Engine Mechanical – V6

Update Number

Date

Section / Subsection Affected

Brief Change Description

22 MAY 2007

Complete Document

THE FOLLOWING CHANGES WERE
MADE:

Page 4 & 5

Page 8, 13, 110-115, 117, 119, 122, 124,
130, 132-134, 139-151, 156-166, 171-179,
186, 187, 190, 193-201, 203, 351, 355.

Figure 6A1 – 100, 102, 151, 152, 171-197,
219-239, 263-285, 299, 302, 303, 306, 312-
327

EN-48313

This C1-file replaces the previous (Holden Rodeo)
C-file

Content page change

Text changes

Graphic changes

New special tool (Timing Chain Retention Tool)

TEXT COLOURS TO INDICATE SPECIFIC APPLICATION

......................................... Text in this colour indicates that the original text has been updated and is to replace

the existing, regardless of model.
