Isuzu KB P190. Manual - part 688
Engine Mechanical – V6
Page 6A1–273
Engine Block Front
Figure 6A1 – 524
Legend
Hole
Tool Number J 42385
Max. Depth in mm
Number Thread
Size Drill
Counter-
bore
Tap Driver
Insert Drill
Tap
1
M8 x 1.25
206
207
208
209
210
28.5
23.0
2
M10 x 1.5
211
212
213
214
215
33.5
27.0
3
M8 x 1.25
207
207
208
209
210
Thru
23.0
4
M8 x 1.25
207
207
208
209
210
Thru
Thru
5
M10 x 1.5
212
212
213
214
215
28.0
28.0
6
M10 x 1.5
212
212
213
214
215
Thru
20.0
7
M10 x 1.5
212
212
213
214
215
Thru
28.8
