11B-54 ANTITHEFT SYSTEM DTC 37 Broken Wire To Passenger Door Step Action Value (s) Yes No 1 Was the Antitheft System Check performed? — Go to Step 2 Go to antitheft System Check 2 Recheck the DTC. 1. Key position is “OFF”. 2. Install the Tech-2 on vehicle. 3. Key position is “ON”. 4. Check the DTC on the Tech-2. — Go to Step 3 Refer to Diagnostic Aids 3 Check the passenger door lock function. 1. Key position is “OFF”. 2. Install the Tech-2 on vehicle. 3. Key position is “OFF”. 4. Observe to display door lock data with the Tech-2. 5. Turn ON by passenger door lock. — Go to Step 4 Go to Step 5 4 1. Key position is “ON”. 2. Observe to display door lock data with the Tech-2. 3. Turn OFF by passenger door lock. — Refer to Diagnostic Aids, and then go to step 5 Go to Step 5 5 1. Check the passenger door lock circuit for an open, short to ground, or short to voltage.
Also, check the motor connector for damage. 2. If a problem found, repair as necessary. — Verify repair Go to Step 6 6 1. Repair or replace the passenger door lock. 2. Check the DTC on the Tech-2. — Go to Step 7 Verify repair 7 Replace the antitheft control unit (ACU). IMPORTANT: The replacement ACU must be Was the action complete? — Verify repair —
|
