Isuzu KB P190. Manual - part 1391
8A-626 ELECTRICAL-BODY AND CHASSIS
No.
Connector face
No.
Connector face
H16
White
Rear body ~ Rear door-RH
H29
(C24SE)
Battery (+) ~ Engine room
H17
Gray
Chassis ~ License plate light
H30
NOT USED
H18
White
Engine room ~ INST
H31
(C24SE)
Engine room ~ Mission
H19
~
H22
NOT USED
H32
(C24SE)
Engine room ~ Rear body
H23
White
Engine ~ Engine room B
H33
White
Engine ~ Engine room
H23
(4JA1T-
(L))
White
Engine room B ~ T/misson
H34
Black
Engine ~ Engine room
H24
~
H25
NOT USED
H35
Gray
Trailer hitch
H26
Black
INST ~ Rear body
H36
White
INST ~ Front door-RH
H27
NOT USED
H37
White
INST ~ Front door-LH
H28
White
Sub harness connector
H38
White
INST ~ Front door-RH
