B1049 – B1052, B1054 – B1057 DRIVER AIRBAG MODULE SRC-19 < COMPONENT DIAGNOSIS > C D E F G I J K L M A B SRC N O P 2. WIRING HARNESS Is there any visible damage to the harness? YES >> Replace the harness. NO >> GO TO 3 3. DRIVER AIR BAG MODULE Replace the driver air bag module. Refer to SR-5, "Removal and Installation" . >> GO TO 4 4. SPIRAL CABLE Replace the spiral cable. Refer to SR-7, "Removal and Installation" . >> GO TO 5 5. AIR BAG DIAGNOSIS SENSOR UNIT Replace the air bag diagnosis sensor unit. Refer to SR-17, "Removal and Installation" >> GO TO 6 6. RELATED HARNESS Replace the related harness. >> END |
