Infiniti G37 Coupe. Manual - part 1062
SUNROOF MOTOR ASSEMBLY
RF-73
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
M
A
B
RF
N
O
P
Removal and Installation
INFOID:0000000001746926
REMOVAL
CAUTION:
• Before removing sunroof motor, check that glass lid is fully closed.
• After removing sunroof motor, do not attempt to rotate sunroof motor assembly as a single unit.
1.
Remove the headlining. Refer to
INT-24, "SUNROOF : Removal and Installation"
2.
Remove sunroof motor assembly mounting screws (A).
Disconnect connector (B) from sunroof motor assembly and
then remove sunroof motor assembly (1).
INSTALLATION
CAUTION:
Before installing the sunroof motor assembly, be sure to the place the link and wire assembly in the
symmetrical and fully closed position.
1.
Move the sunroof motor assembly laterally by little so that the gear is completely engaged into the wire on
the sunroof unit assembly and mounting surface becomes parallel. Then secure the sunroof motor
assembly with screw.
2.
Install the headlining. Refer to
INT-24, "SUNROOF : Removal and Installation"
.
JMKIA0222ZZ
