AV DIAGNOSIS SYSTEM (AV CONTROL UNIT) AV-193 < FUNCTION DIAGNOSIS > [BOSE AUDIO WITHOUT NAVIGATION] C D E F G H I J K L M B A O P STARTING PROCEDURE 1. Start the engine. 2. Turn the audio system OFF. 3. While pressing the “SETTING” button, turn the volume control formed by pressing the “BACK” button. 4. The trouble diagnosis initial screen is displayed, and then the SELF-DIAGNOSIS MODE Confirmation/ Adjustment Display Diagnosis The confirmations of the tint with the color spectrum bar display and Vehicle Signals Diagnosis of signals can be performed for vehicle speed, parking brake, Speaker Test The connection of a speaker can be confirmed by test tone. Climate Control Start auto air conditioner system self-diagnosis. Error History The system malfunction and the frequency when occurring in the past Vehicle CAN Diagnosis The transmitting/receiving of CAN communication can be monitored. AV COMM Diagnosis The communication condition of each unit of Multi AV system can be Camera Cont. The signal connected to camera control unit can be checked and the Delete Unit Connection Log Erase the connection history of unit and error history Initialize Settings Initializes AV control unit memory. Mode Description JSNIA0137GB JSNIA0138GB |
