Hyundai Tiburon (2003 year). Manual - part 82
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Brake System > Parking Brake System > Parking Brake
Assembly > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Brake System > Parking
Brake System > Parking Brake Assembly > Repair procedures
REMOVAL
• The parking brake cables must not be bent or distorted. This will lead to stiff operation and premature
failure.
• Refer to the component as needed during this procedure.
Rear disc brake
1. Release the parking brake lever fully, and remove the parking cable clip (A) from the parking brake cable.
2. Disconnect the parking brake cable (B) from the lever (C).
