± − <± ± ± ± ± *07 Calibrating the Front Passenger’s Weight Variance = (T) (M) 8.6 lbs (3.9 kg) M: Weight measured by the weight scale Weight measured by the tester with the 23-42 SRS General Troubleshooting Information (cont’d) A When the front passenge’s weight sensor and/or front While calibrating the front passenger’s weight sensor • Make sure all components of the front passenger’s seat are correctly installed. • Make sure all option parts such as seat cover are removed. • Position the front passenger’s seat to the rear most position, adjust the seat height to the lowest position, • Make sure nothing is on or under the front passenger’s seat, and there is nothing in the seat-back pocket. • Keep the windows closed. in the service bay. • Make sure the vehicle is on level ground. finish the next step after you start the drive the • Do not expose the front passenger’s seat to sudden temperature change. 1. Position the front passenger’s seat to the rear most position, adjust the seat height to the lowest 2. Connect the Honda Diagnostic System (HDS) to the data link connector (DLC) (A). 3. Drive the vehicle, and accelerate to 20 mph (36 km/ hr), then stop on level ground. 4. From the adjustment menu, select ‘‘SWS INIT.’’ 5. Prepare a weight between 55 to 77 lbs (25 to 35 kg) then measure and note its actual weight (M) with a NOTE: The accuracy of weight scale must be within 2.2 lbs (1 kg). 6. Place the prepared weight on the front passenger’s seat. NOTE: Leave the HDS connected in the Misc Menu. 7. Drive the vehicle, and accelerate to 20 mph (36 km/ hr), then stop on level ground. 8. From the inspection menu, select ‘‘SEAT OUTPUT CHK.’’ The weight (T) of the front passenger’s seat 9. Calculate the variance between the weight measured by the weight scale (M) and by the HDS • If the variance is 8.6 lbs ( 3.9 kg) or less, calibration is complete. Go to step 18. • If the variance is more than 8.6 lbs ( 3.9 kg), remove the seat weight sensors, and reinstall 03/07/29 10:31:11 61S0X050_230_0042 |
