3. Remove the MAF sensor/IAT sensor (C).

4. Install the parts in the reverse order of removal with a new O-ring (D) coated with clean engine oil.

ECT SENSOR 1 REPLACEMENT

1. Remove the air cleaner (see AIR CLEANER REMOVAL/INSTALLATION ).

2. Remove the EVAP canister purge valve (see FTP SENSOR REPLACEMENT ).

3. Unbolt the under-hood fuse/relay box bolt, and move the assembly aside.

4. Drain the engine coolant (see COOLANT CHECK ).

5. Disconnect the ECT sensor 1 connector (A).

Fig. 178: Identifying O-Ring, ECT Sensor 1 And Connector With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

6. Remove the ECT sensor 1 (B).

7. Install the parts in the reverse order of removal with a new O-ring (C) coated with clean engine oil, then

refill the radiator with engine coolant (see COOLANT CHECK ).

ECT SENSOR 2 REPLACEMENT

1. Drain the engine coolant (see COOLANT CHECK ).

2. Remove the splash shield.

3. Disconnect the ECT sensor 2 connector (A).



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element



Fig. 179: Identifying O-Ring, ECT Sensor 2 And Connector With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove ECT sensor 2 (B).

5. Install the parts in the reverse order of removal with a new O-ring (C) coated with clean engine oil, then

refill the radiator with engine coolant (see COOLANT CHECK ).

A/F SENSOR REPLACEMENT

Special Tools Required

O2 sensor socket wrench. Snap-on YA8875, SP Tools 93750, or equivalent, commercially available

1. Disconnect the A/F sensor 4P connector (A), then remove the A/F sensor (B).



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element



Fig. 180: Identifying A/F Sensor 4P And Connector With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Install the parts in the reverse order of removal.

SECONDARY HO2S REPLACEMENT

Special Tools Required

O2 sensor socket wrench, Snap-on YA8875, SP Tools 93750, or equivalent, commercially available

1. Disconnect the secondary HO2S 4P connector (A), then remove the secondary HO2S (B).

Fig. 181: Removing Secondary HO2S With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element



2. Install the parts in the reverse order of removal.

CMP SENSOR B REPLACEMENT

1. Remove the air cleaner (see AIR CLEANER REMOVAL/INSTALLATION ).

2. Remove the EVAP canister purge valve (see FTP SENSOR REPLACEMENT ).

3. Disconnect the CMP sensor B connector (A).

Fig. 182: Identifying O-Ring, CMP Sensor B And Connector With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Remove CMP sensor B(B).

5. Install the parts in the reverse order of removal with a new O-ring (C) coated with clean engine oil.

CKP SENSOR REPLACEMENT

1. Disconnect the CKP sensor connector (A).



2007 Honda Element EX

2007-2008 ENGINE PERFORMANCE PGM-FI System - Element
