Fig. 152: Identifying Transmission Hanger, Bolt And Washer With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

27. 2WD: Apply MTF to the new O-ring (A). Then install the new O-ring and the side cover (B).

Fig. 153: Identifying O-Ring And Side Cover With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

28. 4WD: Apply MTF to the new O-ring (A). Then install the new O-ring, 10 x 20 mm dowel pin (B), and

the transfer assembly (C).



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Fig. 154: Identifying O-Ring, Dowel Pin And Transfer Assembly With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

GEARSHIFT MECHANISM REPLACEMENT



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Fig. 155: Identifying Gearshift Components With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

COMPONENT LOCATION INDEX

2WD



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Fig. 156: Identifying M/T Differential Component Location (2WD)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4WD



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element
