TRANSMISSION FLUID INSPECTION AND REPLACEMENT

1. Raise the vehicle on a lift.

2. Remove the filler plug (A) and washer (B), check the condition of the fluid, and make sure it is at the

proper level (C).

Fig. 2: Identifying Fluid Proper Level
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. If the fluid is dirty, remove the drain plug (A) and drain the fluid.

Fig. 3: Identifying Drain Plug And Drain Fluid With Torque Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Reinstall the drain plug with a new washer, and refill the transmission fluid to the proper level.

Fluid Capacity

2WD: 1.9 L (2.0 US qt) at fluid change

2.15 L (2.3 US qt) at overhaul

4WD: 1.9 L (2.0 US qt) at fluid change



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



2.25 L (2.4 US qt) at overhaul

Always use Honda manual transmission fluid (MTF). Using engine oil can cause stiffer shifting because
it does not contain the proper additives.

5. Reinstall the filler plug (B) with a new washer.

BACK-UP LIGHT SWITCH TEST

1. Disconnect the back-up light switch connector (A).

Fig. 4: Identifying Back-Up Light Switch Connector With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2. Check for continuity between the back-up light switch 2P connector terminals No. 1 and No. 2. There

should be continuity when the shift lever is only in reverse.

3. If necessary, replace the back-up light switch. Apply liquid gasket (P/N 08718-0001) evenly to the

threads of the transmission housing. Install the switch within 5 minutes of applying the liquid gasket.
Tighten the back-up light switch to the specified torque.

TRANSMISSION REMOVAL

Special Tools Required



Engine support hanger, A & Reds AAR-T-12566 *



Engine hanger/adapter VSB02C000015 *



Front subframe adapter VSB02C000016 *

NOTE:



If you apply liquid gasket P/N 08718-0012, the component must be
installed within 4 minutes.



If too much time has passed after applying the liquid gasket, remove
the old liquid gasket and residue, then reapply new liquid gasket.



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



*These special tools are available through the Honda Tool and Equipment Program 1-888-424-6857.

1. Make sure you have the anti-theft code for the audio unit.

2. Turn the steering wheel to the straight-ahead position, then remove the key from the ignition switch and

lock the steering column.

3. Secure the hood in its vertical position (A).

Fig. 5: Identifying Hood In Vertical Position
Courtesy of AMERICAN HONDA MOTOR CO., INC.

4. Disconnect the negative cable from the battery, then disconnect the positive cable.

5. Remove the battery.

6. Remove the air cleaner assembly (see AIR CLEANER REMOVAL/INSTALLATION ).

7. Remove the intake air duct (see step 5 in ENGINE REMOVAL ).

8. Remove the battery base (see step 9 in ENGINE REMOVAL ).

9. Remove the ground cable (A).

NOTE:

Use fender covers to avoid damaging painted surfaces.



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element



Fig. 6: Identifying Ground Cable
Courtesy of AMERICAN HONDA MOTOR CO., INC.

10. Disconnect the output shaft (countershaft) speed sensor connector (B) and back-up light switch connector

(C).

11. Remove the cable bracket (A), then disconnect the shift cables (B) from the top of the transmission

housing. Carefully remove both cables and the bracket together to avoid bending the cables.

Fig. 7: Identifying Cable Bracket And Shift Cables
Courtesy of AMERICAN HONDA MOTOR CO., INC.

12. Carefully remove the slave cylinder (A) to avoid bending the clutch line (B).

Fig. 8: Identifying Slave Cylinder And Clutch Line
Courtesy of AMERICAN HONDA MOTOR CO., INC.

13. Remove the two upper transmission mounting bolts (A).

NOTE:

Do not press the clutch pedal after the slave cylinder has been removed.



2007 Honda Element EX

2007-2008 TRANSMISSION Manual Transmission - Element
