15. Check for continuity between shift solenoid harness connector terminal No. 1 and the shift solenoid valve C connector terminal. Fig. 154: Checking Continuity Between Shift Solenoid Harness And Shift Solenoid Valve Connector Is there continuity? YES -Replace shift solenoid valve C (see SHIFT SOLENOID VALVE REPLACEMENT ), then go to NO -Replace the shift solenoid harness (see SHIFT SOLENOID VALVE REPLACEMENT ), then go 16. Reconnect all connectors. 17. Turn the ignition switch ON (II). 18. Clear the DTC with the HDS. 19. Start the engine in the P position, and wait for at least 1 second. 20. Drive the vehicle in 1st gear in the D position for at least 1 second. 21. Check for DTCs with the HDS. Is DTC P0980 indicated? YES -Check for poor connections or loose terminals between shift solenoid valve C and the PCM, then NO -Go to step 22. 22. Monitor the OBD STATUS for P0980 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES -Troubleshooting is complete. If any other DTCs were indicated in step 21, go to the indicated
2007 Honda Element EX 2007-2008 TRANSMISSION Automatic Transmission - Element
|
