2. Remove the front seat belt buckle (see FRONT SEAT BELT BUCKLE ). (A). Fig. 45: Removing Rear Seat Access Knob 4. Pull back the cap (A) to release the hooks (B), and remove the screws, then remove the height handle (C). Fig. 46: Removing Height Handle 5. Remove the recline outer cover (A). 1 Remove the recline knob (B) and screw (C). 2 Gently pull out the cover, then detach the clips (D), and release the 3 Release the rear seat access lever (F).
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Seats - Civic (Except Hybrid)
|
