Fig. 33: Detaching Clips And Hooks Pulling Bottom Of Back Cover 6. Pull the side airbag harness (A) out through the loop (B), and release the hook (C), then pull the seat-back cover (D) back. Fig. 34: Pulling Side Airbag Harness Out Through Loop 7. Detach the harness clip (A), and pull the side airbag harness (B) out through the harness hole (C) in the seat-back cover and seat frame.
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Seats - Civic (Except Hybrid)
|
