Great Wall Hover. Manual - part 101

Appendix A-5

drive shaft bolt

the fixed torque of bolt 1 in the Figure is  78

5N

m

front axle drive shaft assembly

transmission assembly

rear axle drive shaft assembly

rear axle assembly

petrol lien joint

petrol line joint tightening torque is  16

2 N

torque wrench

petrol pipe joint

two way valve

Appendix A-6

Driver steering oil pump installation

Fixed torque of tubular hexagon bolt 1 in the Figure is

4 0 N

m

Multi-wedge belt

Multi-wedge belt 4PK1100 tension is 500

50N

Torque

Torque

multi-wedge belt 4PK1100

driver steering oil pump

cover lock mounting bolt

effect

c

over lock mounting bolt’s torque is 9

2N

m

the cover lock can be opened freely, the position is reliable

without any jam.

cover lock cable

cover lock buckle

fastening blot

cover lock mounting bracket

Appendix A-7

The fixed torque of bolt 1 in the Figure is 6

1N

m

Out handle can be normally and efficiently used, no linkage

falling off, the backup door can be opened and closed freely

without any jam nor unlocking.

Handle confirmation

rear door assembly

backup door bottom buckle

backup door lock

backup door out handle

The door can be opened and closed smoothly without any jam nor

unlocking.

Torque wrench

door lock assembly

Appendix A-8

front windshield glass

Apply washer on the front windshield

glass-sticking region

Evenly apply it on the sticking region with the width of about

25mm and completely volatilize it.

Viewing confirmation

Viewing confirmation

Apply base-coater on the front

windshield glass-sticking region

Shake the base-coater to be sufficiently even followed by the

even application on the sticking region with the width of about

20mm and dry it for 2-15 minutes

Apply washer on front windshield

glass

Wash the glass frame with the width of about 25mm,

instantly clean it and volatilize the washer completely.

Apply adhesive on front windshield

glass

Shake the glass base-coater to be sufficiently even followed

by the even application on the glass frame with the width of

about 20 and dry it for 2-15 minutes

Apply base-coater on front

windshield glass

Vertically apply the glass adhesive on the glass frame and

make it even and continuous. Height: 18mm, width: 12mm

Front windshield glass fixing

Instantly install and fix the glass after the glass adhesive

application. Set the left and right clearance between front

windshield glass and the glass frame to be 12mm

Viewing confirmation

Viewing confirmation

Viewing confirmation

Viewing confirmation

Wash, base-coat and stick according to the corresponding positions showed by the broken line in the Figure
