Shifting point Opening degree of throttle position Shifting 1/2 2/3 3/4 4L Opening degree of throttle position shifting 1/2 2/3 3/4 4L 0%
10 20 34 63 0% 14
26 41
87 40%
26
47 82 95 40% 30 56 76
113
100% (WOT)
53 93 126 150 100% (WOT) 53
94 127
152 decreasing 55 89 137
152 decreasing 55 96 137 152
Table 9.3- Shifting point-km/h Maximum speed of typical Gear-decreasing of vehicle
The Gear-decreasing will be disabled when beyond the following speed. Gear-decreasing type Speed point for disable of Gear-decreasing Manual 2-1 In 59 km/h Manual 3-2 89 km/h Manual 4-3
119 km/h Manual 4-2 (4-2 direct) 68 km/h Manual 4-2 (sequence of 4-3-2) 89 km/h Figure 9.4 - Special tools for maximum disable speed of manual Gear-decreasing Special tools tools Part No. Platform bracket of transmission
oil pump remover
Cross shaft disassembly /installation (brake lever)
clutch spring compressing tools
clutch assembly clearance positioning tools
Shaft end floating connector
Shaft end floating measuring tools
cross shaft seal disassembly tools
cross shaft seal installation tools
Pump sealing installation tools
Sealing ring expander extender /compressor
Cross shaft lever disassembly /installation (disable switch)
solenoid valve /electric heating regulator, electric meter
solenoid valve, platform meter
Assembly ball spool
Sealing gasket disc
Figure 9.5 Special tools |
