c. Remove the high/low drive declutch shift shaft elastic cylindrical pin

d. Remove the 2

nd

/4

th

 declutch shift shaft elastic cylindrical pin

e. Use the circlip pliers to remove the bearing snap ring

f. Use the rubber hammer to knock out the transfer case cover assembly

slightly and remove the transfer case cover assembly.

b. Remove the select & shift seating elastic cylindrical pin

Transmission-33

10. Remove the high and low gear drive declutch shift shaft

11.Remove the second and fourth drive declutch shift shaft

12. Use the plastic hammer to knock out the rear output shaft

      assembly, front output shaft assembly and chain out slightly

13. Remove the second/fourth shift block and high and low gear

      shift fork

14. Remove the housing of transfer case

a. Use the wrench to remove 4 bolts M10

1.25

35 and 2 nuts

M10

1.25 connected the gearbox and tranafer case housing

Caution: The tightening torque is 30

42 N•m when install

the connecting bolt of gearbox and housing of transfer case

b. Remove the housing of transfer case

15.Remove a location pin

For the disassembly of gearbox refer to “Disassembly of gearbox in

SC5M2D

C”

Transmission-35

Disassembly of rear output shaft assembly

a. Use the special tools to remove the lock nut

Caution: The tightening torque is 87-120N

m when in-

stall the lock nut.

b. Remove the ball bearing

Rear output shaft assembly

c

Remove the oil guide plate

circlips for shaft

high and low
 gear sleeve

needle bearing

high and low gear hub

  needle bearing

 low-speed driven gear

rear output shaft

ball bearing

 spacing plate

second/ fourth drive gear hub

second/fourth
 drive geared sleeve

sprocket needle bearing bushing

needle
 bearing

  drive sprocket

spacer of
drive sprocket

oil guide plate assembly

ball bearing
assembly

87-120

N

m:   specified torque

    Used component which can not be used any more.



Use the special tools

d

Remove the spacing ring
