(3) Pull the cargo lamp switch and bezel away from the pillar far enough to access and disconnect (4) From the back of the switch bezel, depress the two latches on the outside of the cargo lamp switch INSTALLATION INSTALLATION - INSTRUMENT PANEL (1) From the front of the accessory switch bezel, align the cargo lamp switch body with the opening in (2) From the back of the accessory switch bezel, reconnect the vehicle wire harness connector for the (3) Reinstall the accessory switch bezel onto the instrument panel. (Refer to 23 - BODY/INSTRU- PANEL/ACCESSORY SWITCH BEZEL - INSTALLATION). (4) Reconnect the battery negative cable. INSTALLATION - BULKHEAD (1) From the front of the switch bezel, align the cargo lamp switch body with the opening in the bezel (2) Reconnect the vehicle wire harness connector for the cargo lamp switch to the receptacle on the (3) Using hand pressure, firmly and evenly press the cargo lamp switch and switch bezel into the (4) Reconnect the battery negative cable. INSTALLATION - REAR PILLAR (1) From the front of the switch bezel, align the cargo lamp switch body with the opening in the bezel (2) Reconnect the vehicle wire harness connector for the cargo lamp switch to the receptacle on the (3) Using hand pressure, firmly and evenly press the cargo lamp switch and switch bezel into the (4) Reconnect the battery negative cable. DOME / READING LAMP BULB REMOVAL (1) Disconnect and isolate the battery negative cable. (2) Remove the dome/reading lamp unit from its mounting location, but do not disconnect the vehicle LAMP UNIT - REMOVAL). (3) Grasp the lamp housing in one hand and care- fully pull the bulb out of the bulb holder with the INSTALLATION (1) Grasp the dome/reading lamp housing in one hand and carefully insert the bulb into the bulb (2) Reinstall the dome/reading lamp unit into its mounting location. (Refer to 8 - ELECTRICAL/ (3) Reconnect the battery negative cable. DOME / READING LAMP UNIT REMOVAL (1) Disconnect and isolate the battery negative cable. (2) Insert the tip of a small flat-bladed screwdriver into the notch on one edge of the dome/reading lamp Fig. 5 Dome/Reading Lamp Bulb Remove/Install 1 - LAMP HOUSING 8L - 32 LAMPS/LIGHTING - INTERIOR VA |
