B1B07-DRIVER AIRBAG SQUIB 2 CIRCUIT SHORT TOGETHER (CONTINUED) For the Air Bag System circuit diagram (Refer to 8 - ELECTRICAL/RESTRAINTS - SCHEMATICS AND DIA- For a complete wiring diagram Refer to Section 8W. • When Monitored: • Set Condition: Possible Causes (R61) DRIVER SQUIB 2 LINE 1 SHORTED TO (R63) DRIVER SQUIB 2 LINE 2 CLOCKSPRING DRIVER AIRBAG OCCUPANT RESTRAINT CONTROLLER Diagnostic Test 1. DETERMINE ACTIVE OR STORED DTC NOTE: Ensure the battery is fully charged. NOTE: The Scan Tool, SRS Airbag Load Tool MRL 8443 and NOTE: When reconnecting airbag system components the Igni- Is the DTC active or stored? ORC - ACTIVE DTC Go To 2 ORC - STORED DTC Go To 6 HB RESTRAINTS - ELECTRICAL DIAGNOSTICS 8O - 61 |
