INSTALLATION 1. Install the TRS (2) to the manual shaft. Make sure TRS locating pin rests in manual valve bore slot. 2. Install the TRS/manual shaft retaining screw (1) and torque to 5 N·m (45 in. lbs.) torque. 3. Install the manual shaft seal (1). 4. Install valve body to the transmission. (Refer to 21 - TRANSMISSION//AUTOMATIC - 42RLE/VALVE HB AUTOMATIC TRANSMISSION 42RLE - SERVICE INFORMATION 21 - 321 |
