TORQUE TORQUE CHART 5.7L ENGINE DESCRIPTION N·m Ft. In. Lbs. Lbs. Block Pipe Plugs 20 — 177 (3/8 NPT) 27 — 240 Camshaft Sprocket—Bolt 122 90 — Camshaft Tensioner Plate—Bolts 28 — 250 Timing Chain Case Cover—Bolts 28 — 250 Lifting Stud 55 40 — Connecting Rod Cap—Bolts 21 plus 90° Turn 15 plus 90° Turn — Main Bearing Cap—Bolts 27 plus 90° Turn — — Crossbolts 28 — — Cylinder Head—Bolts Step 1 34 25 — Step 2 54 40 — Step 3 Turn 90° Turn 90° — M-8 Bolts — Step 1 20 15 — Step 2 34 25 — Cylinder Head Cover—Bolts 8 — 70 Exhaust Manifold to Cylinder Head 25 — 220 Flexplate to crankshaft—Bolts 95 70 — Flywheel to crankshaft—Bolts 75 55 — Front Insulator—Through bolt/nut 95 70 — Front Insulator to Support Bracket —Stud Nut (4WD) 41 30 — —Through Bolt/Nut (4WD) 102 75 — Front Insulator to Block—Bolts (2WD) 95 70 — Generator—Mounting Bolt 55 40 — Intake Manifold—Bolts Refer to Procedure Lifter Guide Holder 12 — 106 Oil Pan Bolts 12 - 105 Oil Dipstick Tube 12 — 105 Oil Pan—Drain Plug 34 25 — Oil Pump—Attaching Bolts 28 — 250 Oil Pump Pickup Tube – Bolt and Nut 28 — 250 Rear Seal Retainer Attaching Bolts 15 — 132 Rear Insulator to Bracket— 68 50 — Through-Bolt (2WD) HB ENGINE - 5.7L SERVICE INFORMATION 9 - 1343 |
