5A-100 AUTOMATIC TRANSMISSION Planet Carrier Assembly and Centre Support To assemble the planet carrier assembly and centre support, 1. Check the carrier and planet assembly for any damage or irregularity and ensure that all pinions rotate freely and 2. Install the one way clutch (OWC) retainer to the planet carrier with the inner edge pointing downwards. Inspect 3. Install the outer race in the drum. Press the race to the bottom of the drum and install the retaining circlip. Ensure Refer to figure 8.21. 4. Install the OWC into the outer race with the lip edge uppermost. Lubricate the sprags with automatic 5. Check that the plugs are fitted to the centre support, then assemble the centre support into the OWC, ensuring that Figure 8.20 - Planet Carrier Assembly and Centre Support 6. Lubricate the No.9 needle thrust bearing and the thrust washer with petroleum jelly and fit them to the rear face of 7. Install the planet assembly and the centre support into the case, and align the centre support mounting bolt holes. 8. Install the centre support bolts finger tight. 9. Install the circlip retainer ensuring that the circlip is completely seated in the groove of the case. 10. Remove the centre support bolts and apply Loctite 222 or equivalent to the threads. Install the bolts and torque to |
