1B2-68 M161 ENGINE MECHANICAL 7. Remove the bearing cap, and remove the intake and the exhaust camshaft. Installation Notice Tightening Torque 22.5 - 27.5 Nm Notice Check the numbers on the bearing cap not to be miked 8. Apply the engine oil on the valve tappet and camshaft bearing. 9. Installation should follow the removal procedure in the reverse order. Notice l Base circle of cam should cantact with the valve tappet. l Install the camshaft bearing caps according to the numbers on the cylinder head cast and bearing cap. 10. Check the camshaft timing position. |
