GLASS AND MIRRORS  9L – 13

D109E526

2. Install the division bar with the guide rail inside bolt,

the guide rail outside bolt and the guide rail screw.

3. Inside the outside rearview mirror. Refer to “Outside

Rearview Mirror” in this section.

4. Install the front door seal trim. Refer to Section 9P,

Doors.

D19E523

REAR DOOR GLASS

Removal Procedure

1. Remove the glass run. Refer to Section 9P, Doors.

2. Remove the glass.

D

Remove the bolts (1).

D

Remove the glass (2).

Notice: Make sure not to contact the glass with the body
to prevent the paint damage.

D19E524

Installation Procedure

1. Install the glass with the bolts.

2. Install the glass run. Refer to Section 9P, Doors.

D19E527

INSIDE REARVIEW MIRROR

Removal Procedure

1. Remove the inside rearview mirror.

D

Remove the screw (1).

D

Remove the inside rearview mirror (2).

9L – 14  GLASS AND MIRRORS

D19E528

Installation Procedure

1. Install the inside rearview mirror with the screw.

D19E529

OUTSIDE REARVIEW MIRROR
(MANUAL)

Removal Procedure

1. Remove the outside rearview mirror cover from the

outside rearview mirror.

D19E530

2. Remove the outside rearview mirror.

D

Remove the screws (1).

D

Remove the outside rearview mirror (2).

D19E531

Installation Procedure

1. Install the outside rearview mirror with the screws.

2. Install the outside rearview mirror cover.

GLASS AND MIRRORS  9L – 15

D29L001

OUTSIDE REARVIEW MIRROR
(CABLE)

Removal Procedure

1. Pry off the outside rearview mirror inside trim cover

(1).

2. Remove the mirror adjusting lever mounting nuts (2).

D109E529

3. Remove the outside rearview mirror cover from the

outside rearview mirror.

D109E530

4. Remove the outside rearview mirror.

D

Remove the screws (1).

D

Remove the outside rearview mirror (2).

D109E531

Installation Procedure

1. Install the outside rearview mirror with the screws.

2. Install the outside rearview mirror cover.

3. Install the mirror adjusting lever with the nuts.

4. Install the outside rearview inside trim cover.

9L – 16  GLASS AND MIRRORS

D109E529

OUTSIDE REARVIEW MIRROR
(ELECTRIC)

Removal Procedure

1. Disconnect the negative battery cable.

2. Remove the outside rearview mirror cover from the

outside rearview mirror.

D209B108

3. Remove the outside rearview mirror.

D

Remove the screws (1).

D

Disconnect the electrical connector (2).

D

Remove the outside rearview mirror (3).

D109E531

Installation Procedure

1. Connect the outside rearview mirror.

2. Install the outside rearview mirror with the screws.

3. Install the outside rearview mirror cover.

4. Connect the negative battery cable.
