FATC-HAVC 7D-7 FUNCTION DESCRIPTION 1. AUTO switch l By pressing the AUTO switch, set temperature, l Following items will be controlled automatically - Mode and intake door - Temperature door - Blower fan speed - Compressor ON/OFF control l When AUTO switch is released, other functions will 2. MODE switch l By pressing the MODE switch while the AUTO switch ® B/L ® FLR ® MIX ® VENT. 3. OFF switch l Press this switch and the airconditioner system will 4. Temperature UP/DOWN switch l This switch is a switch increasing or decreasing set l By operating the switch, set temperature will be l Set temperature range is 17 - 32°C. l Max. cold function will be performed at set temperature l When pressed more than 1 second, it will be l When it changed 17.5°C ® 17°C, 31.5°C ® 32°C and DOWN switch is pressed after 17°C or UP switch is 5. DEFROST switch l By pressing this switch, DEF will turn on and mode l Recirculation/fresh air switch will be fixed as FRESH. l When airconditioner is turned ON and ambient l Selection of airconditioner OFF is possible by manual. 6. A/C switch l The airconditioner system will be turned ON or OFF 7. Recirculation•fresh air switch l Air intake will be automatically switched to recirculation ® FRE) by pressing this switch. 8. Blower switch (UP/DOWN) l Blower speed can be controlled by manual and if fan l When 6 segments are turned on, it is max. HI l When pressed more than 1 second, it will be l When segment is changed stage 2 ® stage 1 (LO), stage 5 ® stage 6 (HI) and HI switch is pressed in HI status or DOWN switch is pressed in LO status, there l When switch is operated in OFF status, it will be |
