1B2-22 M161 ENGINE MECHANICAL Removal & Installation Procedure 1. Remove the belt pulley after removal of poly v-belt. Installation Notice 2. Disconnect the hydraulic pipe of the power steering pump and drain the oil. 3. Unscrew the bolts (arrows) and remove the steering pump. Installation Notice Notice Pull the tensioning pulley counterclockwise as shown in the 4. Remove the compressor after disconnecting the wiring connector and refrigerant pipe of A/C compressor. Notice Discharge all the refrigerant before removing the pipes. Tightening Torque 40.5 - 49.5 Nm Tightening Torque 22.5 - 27.5 Nm |
