7-1

Lubrication

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΛΦ45/55 series

5

7. LUBRICATION

7.1 LUBRICATING ACCORDING TO Y-SERVICE LUBRICATION SCHEDULE

Note:

The lubricating points marked below with an (S)

indicate that the lubricating point is positioned on

both the left-hand and right-hand side of the

vehicle.

Lubricating stub axles (S), general
1.

To make sure that the grease can penetrate

adequately, the stub axles should be

lubricated in unloaded condition. The front

axle should therefore be completely jacked

up; make a complete steering movement

from left to right during greasing.

2.

Lubricate the stub axles until grease comes

out.

F36, F48 and F60 (S) front axles
1.

The F36 and F48 front axles have a grease

nipple on the top side and the underside. The

F60 front axle has a grease nipple only on

the underside.

S7 00 545

S7 00 591

S7 00 590

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

7-2

©

 200515

Lubrication

5

ΛΦ45/55 series

152N (S) front axle
1.

The 152N front axle has a grease nipple on

the top side and underside.

G000189

©

 200515

7-3

Lubrication

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΛΦ45/55 series

5

7.2 LUBRICATE ACCORDING TO X-SERVICE LUBRICATION SCHEDULE

Lubricating the selector rod
1.

Tilt the cab.

2.

Apply a thin, even layer of grease to the

indicated part.

Note:

The locking hook under the cab must not be

lubricated.

Lubricating the fifth wheel
3.

Lubricate the fifth wheel via the grease

nipple.

Lubricating the trailer coupling
4.

Lubricate the trailer coupling via the grease

nipple.

V3 00 380

G000192

G000188
