DAF LF45, LF55 Series. Manual - part 652

©

 200515

3-37

Inspection and adjustment

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΛΦ45/55 series

5

3.44 INSPECTING THE REAR AXLE WHEEL BEARING PLAY

Inspecting the rear axle wheel bearing play
1.

Jack up the rear axle until the wheels are

clear from the floor and position suitable

stands under the axle.

2.

Check the wheel bearings manually for

noticeable play.

Note:

If noticeable play is detected, the wheel

bearing play should be re-adjusted.

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

3-38

©

 200515

Inspection and adjustment

5

ΛΦ45/55 series

3.45 CHECKING THE CLAMP OF THE DRIVE SHAFT UNIVERSAL JOINT

1.

Retighten the attachment bolts (1) of the

clamps to the specified tightening torque,

see "Technical data".

Note:

The attachment bolts must not turn when

they are retightened.

Attachment bolts that turn when they are

retightened must be loosened and checked.

2.

Tighten the loosened attachment bolts to the

specified torque. See "Technical data".

V3 00 377

1

©

 200515

4-1

Removal and installation

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

ΛΦ45/55 series

5

4. REMOVAL AND INSTALLATION

4.1 REMOVAL AND INSTALLATION, INTERIOR FILTER ELEMENT

Removing the interior filter element
1.

Open the grille.

2.

Remove the attachment bolts (1) from the

grate (2) on the underside of the filter casing.

3.

Open the grate and remove the interior filter

element.

Installing the interior filter element
1.

Install the interior filter element. Close the

grate (2) and fit the attachment bolts (1).

2.

Close the grille.

Engine, cooling system and fuel system

1

2

K1 01 147

EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES

4-2

©

 200515

Removal and installation

5

ΛΦ45/55 series

4.2 REMOVAL AND INSTALLATION, AIR FILTER ELEMENT

Removing the air filter element
1.

Loosen all clamping brackets on the air filter

cover.

2.

Remove the air filter cover.

3.

Remove the air filter element.

4.

Clean the inside of the air filter housing and

the air filter cover.

5.

Clean the rubber sealing valves (1 and 2) on

the filter housing. Check the sealing valve for

damage.

Installing the air filter element
1.

Fit the air filter element in the air filter

housing.

2.

Fit the air filter cover.

3.

Install all the clamping brackets.

4.

Reset the air filter indicator (3) by pressing

the knob on the indicator.

I4 00 535

3

1

2
