© 200505 4-31 Removing and installing BE ENGINE ΛΦ45/55 series 2 2 8. Remove the attachment bolts from the timing gear case and remove it. Installing the timing gear case Apply a sealant to the sealing surface of the cylinder block. See "Technical data". Apply the sealant in accordance with the pattern and at the indicated location. The bead has to be 1.5 to 2.0 mm thick. Fit the timing gear case with liquid sealant and tighten the attachment bolts to the specified torque. See "Technical data". Note: If too much sealant is used, or if the sealant is applied in a wrong place, this may cause obstruction of an oil channel or oil sump ventilating duct. This could result in serious damage. 2. Fit the sump bolts and tighten them to the specified torque. See "Technical data". 3. Fit the camshaft gear. 4. Fit the high-pressure pump. 5. Fit the air compressor. 6. Fit the steering pump. 7. Fit the flywheel housing. M201147 M201242 |
