4-3

Removing and installing

BE ENGINE

ΛΦ45/55 series

2

2

Installing the engine mounts
1.

Tighten the engine mounting attachment

bolts to the specified torque. See "Technical

data".

2.

Fit the viscous fan clutch with the fan.

Tighten the attachment bolts to the specified

torque. See "Technical data".

3.

Fit the connector of electronic unit ECS-DC3.

4.

Fit the oil supply pipe.

5.

Fit the heater hose bracket at the top of the

radiator.

6.

Fit the bracket for the air-conditioning pipes

at the top of the radiator.

7.

Fit the torque rod bracket between the

engine and the radiator.

8.

Fit the air inlet hoses between the engine

and the air cooler.

9.

Fit the coolant hoses between the engine,

radiator and the header tank.

10. Fit the torque rod between the radiator and

the engine.

11. Fill the cooling system. See "Draining and

filling".

12. Connect the battery earth lead.

BE ENGINE

4-4

©

 200505

Removing and installing

2

ΛΦ45/55 series

2

4.3 REMOVAL AND INSTALLATION, VALVE COVER

When the engine or parts thereof are

opened, dirt may enter. This may

cause serious damage to the engine.

The engine should therefore be

cleaned thoroughly before it is

opened.

Removing the valve cover
1.

Clean the area around the valve cover.

2.

Remove the banjo bolt and the attachment of

the plastic crankcase breather tube.

3.

Remove the valve cover attachment nuts.

4.

Remove the valve cover.

Installing the valve cover
1.

Clean the sealing surface of the valve sleeve

and the valve cover.

2.

Check the valve cover gasket. If it is not

damaged it may be re-used.

3.

Fit the valve cover gasket to the valve cover.

4.

Fit the valve cover.

5.

Fit the attachment nuts of the valve cover

and tighten them to the specified torque. See

"Technical data".

6.

Fit the plastic crankcase breather tube and

the banjo bolt to the valve cover.

}

©

 200505

4-5

Removing and installing

BE ENGINE

ΛΦ45/55 series

2

2

4.4 REMOVAL AND INSTALLATION, VALVE SLEEVE

When the engine or parts thereof are

opened, dirt may enter. This may

cause serious damage to the engine.

The engine should therefore be

cleaned thoroughly before it is

opened.

Removing the valve sleeve
1.

Remove the valve cover.

2.

Detach the feed-through connectors from the

injectors.

3.

Remove the injector wiring from the

injectors.

4.

Remove the attachment bolts from the valve

sleeve.

5.

Remove the valve sleeve with the gasket.

Installing the valve sleeve
1.

Clean the sealing surface of the cylinder

head and valve sleeve.

2.

Check the valve sleeve gasket. If it is

undamaged, it may be re-used. Fit the valve

sleeve gasket onto the valve sleeve.

3.

Fit the valve sleeve.

4.

Tighten the valve sleeve attachment bolts to

the specified torque. See "Technical data".

Tightening the injector wiring to a

higher torque than specified may

cause damage to the injector.

}

M201082

}

BE ENGINE

4-6

©

 200505

Removing and installing

2

ΛΦ45/55 series

2

5.

Fit the injector wiring on the injectors and

tighten it to the specified torque. See

"Technical data".

6.

Fit the feed-through connectors of the

injectors.

7.

Fit the valve cover.
